It includes various types. For example, analog output modules such as 07aa60r1 can output signals in the range of 4 - 20mA; digital output modules like 07ab60r1; analog input modules such as 07ea60r1 can receive and process analog signals. There are also relay output modules such as 07ab63br1 and 07ab67r1, which can achieve signal isolation and control.
There are 6-slot rack modules such as 07be60r1 and 10-slot expansion rack modules like 07be62r1, which are used for installing and expanding the system. decentral input/output couplers such as 07br60r1 and 07br61r1; bus coupler modules such as 07bv60r1; fieldbus coupler modules such as 07cs61, etc. These modules work together to achieve the communication, expansion and control functions of the system.
Although there is no specific feature introduction for this series of products, referring to general programmable controllers, it may have the following features:
- High Reliability: Through strict component screening and aging, the I/O interface circuit adopts photoelectric isolation, enabling it to operate stably in industrial environments with a relatively long mean time between failures.
- Complete Functions: In addition to basic logic processing functions, it can be used in the field of digital control in conjunction with various special function modules, and can also achieve communication with the upper computer to meet a variety of industrial control needs.
- Easy to Operate: Program input and modification are convenient. It provides multiple programming languages and has a self-diagnosis function, which is convenient for maintenance personnel to troubleshoot and repair faults.
- Strong Flexibility and Expandability: It can be expanded in terms of capacity, function, application and control range according to the application scale, reducing the workload of design, programming and installation, and facilitating the realization of process monitoring and control.
Based on the overall application scope of ABB programmable controllers, the Procontic T200 series may be applied in the following fields:
- Municipal Environmental Protection: Urban water supply, sewage treatment, reclaimed water reuse, urban heating, pumping stations and other links.
- Industrial Production: Metallurgy, electric power, papermaking, ship electrical control, mechanical compressors, air conditioning and refrigeration, conveying machinery, building materials and cement, chemical industry and other industries.
Transportation Field: Rail transit, road traffic, tunnel ventilation, etc.
The following are some picture examples of relevant modules of the ABB Procontic T200 series programmable controllers:
Input/Output Modules
- 07aa60r1 Analog Output Module: It is used to output signals in the range of 4 - 20mA. It usually has standard signal interfaces and electrical connection terminals. There may be indicator lights on the appearance to display the working status of the module.
- 07ab60r1 Digital Output Module: It has multiple digital output channels and can be connected to external devices to achieve the control of digital signals. Generally, there are output status indicator lights on the module.
- 07ea60r1 Analog Input Module: It can receive and process analog signals. It has signal input terminals and relevant electrical protection circuits. There may be parameter setting interfaces or DIP switches.
Other Modules
- 07be60r1 6-slot Rack Module: It is used to install other functional modules, providing mechanical support and electrical connections. It usually has multiple slots and fixing devices, which are convenient for plugging and fixing the modules.
- 07br60r1 decentral Input/Output Coupler: It realizes decentralized input and output control. It has communication interfaces and input/output channels, and can carry out data transmission and interaction with other modules or devices.
- 07bv60r1 Bus Coupler Module: It is used to connect to the fieldbus to achieve communication with other devices or control systems. There are bus interfaces and communication status indicator lights on the appearance.
