NI PXI-2522 Switch Module
NI PXI-2522 High-Density Switch Module
Product Highlights
The NI PXI-2522 revolutionizes automated test systems with its 64-channel matrix configuration and 1-wire architecture. Featuring ultra-low thermal offset (±1 μV) and 200 V/1 A switching capacity, this module delivers lab-grade precision in PXI format. Its patented crosspoint technology ensures signal integrity for sensitive measurements.
Technical Specifications
| Brand | National Instruments (NI) |
| Switching Type | 1-Wire Matrix (64x1) |
| Max Voltage/Current | 200 VDC/1 A |
| Dimensions | 3U PXI Module (160 x 100 x 30 mm) |
Application Scenarios
Ideal for:
- Multiplexed sensor networks in industrial IoT
- Battery test systems for EV manufacturing
- RF signal routing in telecom test racks
We maintain 300+ compatible modules including PXI chassis and specialized cables for complete system integration.
About Guizhou Yuanmiao
As global specialists in industrial automation since 2008, we supply 32+ premium brands including NI, Siemens, and ABB. Our technical team provides:
- 1-year warranty with traceable certification
- 24/7 technical support via WhatsApp 📱
- Same-day shipping from multiple global warehouses
