CPU Type:Compact

Series:S7-300

Function Module:CPU 314C-2 DP

Communication Interface:MPI

Digital Inputs:24

Digital Outputs:16

Analog Inputs:4

Analog Outputs:2

Temperature Sensor:1 Pt100

High-Speed Counters:4

Operating Voltage:24V DC

Memory Capacity:192KB

Dimensions (WxHxD):132mm x 152mm x 131mm

Weight:0.733kg

Operating Temperature Range:-25°C to +60°C

    The SIEMENS S7-300 Compact CPU 314C-2 DP is engineered for high performance and reliability in industrial applications. It seamlessly integrates MPI (Multiprotocol Interface) for easy communication with a wide range of devices.

    With its robust 192KB working memory, this CPU supports complex programming needs, enabling the execution of sophisticated control algorithms. The integration of 24 digital inputs and 16 digital outputs provides ample flexibility for signal handling.

    Equipped with 4 analog inputs and 2 analog outputs, it can accurately manage temperature sensors and other continuous process variables, ensuring precise control over critical processes. The inclusion of a single Pt100 sensor connection allows for temperature measurement in various applications.

    The addition of four high-speed counters (operating at 60kHz) is ideal for timing and position control tasks, making it suitable for applications requiring fast and accurate data acquisition and processing.

    Featuring an integrated 24V DC power supply, this CPU ensures stable operation without the need for external power sources. Its compact size and lightweight design facilitate easy installation in confined spaces, enhancing its versatility in diverse industrial settings.
