Power Output:7.5 kW / 10 HP

Operating Voltage:230 V AC

Operating Frequency:50 Hz

Protection Class:IP 54

Control Interface:Full Color LCD Display

Motor Control Type:Vector Control

Invertor Technology:IGBT

Motor Protection:Overload Protection

Communication Interface:Ethernet/IP

Enclosure Type:Flange Mounted, Front Chassis

Input Current:3.5 A

Output Current:3.5 A

Environmental Compatibility:Indoor/Outdoor Use

Maintenance:Remote Monitoring & Diagnostic Capabilities

    The Allen-Bradley AB 22F-D1P5N103 AC Drive is engineered to provide unparalleled precision and reliability in demanding industrial environments. Its advanced control system ensures smooth operation across a wide range of applications, from heavy machinery to sensitive process controls.

    Equipped with a full numeric LCD interface, this drive offers intuitive operation and easy monitoring of critical parameters such as speed, torque, and current. The enhanced control feature allows for fine-tuning of performance, making it suitable for applications requiring high accuracy and responsiveness.

    Designed with a robust front chassis (IP 20) and rear heat sink (IP 66), the AB 22F-D1P5N103 is built for both indoor and outdoor use, ensuring durability and protection against dust and water ingress. The enclosure is compliant with NEMA/UL standards, ensuring safety and reliability in various industrial settings.

    Featuring a manual interface with a resistor included, the drive provides a flexible control option that can be adapted to different user preferences and system requirements. This feature, combined with the option for filtered frames, caters to a broad spectrum of application needs, enhancing efficiency and reducing maintenance requirements.

    Ideal for integration into modern industrial automation systems, the Allen-Bradley AB 22F-D1P5N103 AC Drive leverages Ethernet/IP for seamless communication with other components of the production line. This not only simplifies installation but also facilitates the implementation of advanced control strategies, such as predictive maintenance and remote diagnostics.
