Model Number:IS200VTURH1BAC

Series:Mark VI

Manufacturer:GE-FANUC

Functional Acronym/Abbreviation:VTUR

Model Type:Protection Board

Supported Function:Primary Turbine Protection

Pulse Rate Range:2 Hz to 20 kHz

Pulse Rate Accuracy:0.05% of Reading

Number of Trip Solenoids:3

Contact Voltage Sensing:20 V dc for HI and 6 V dc for LO

Supported Applications:Steam or Gas Turbines

    The GE-FANUC IS200VTURH1BAC Control Board is engineered with triple modular redundant (TMR) architecture, ensuring unparalleled reliability and accuracy in complex industrial environments. This cutting-edge design allows for seamless integration into existing Mark VI systems, enhancing overall system performance and reducing downtime.

    Featuring a robust pulse rate mechanism, this control board is capable of operating within a wide range of frequencies, providing unparalleled precision in monitoring and controlling turbine operations. Its advanced magnetic relay system ensures swift and reliable response to potential safety issues.

    The IS200VTURH1BAC is specifically designed to safeguard against over-speed events, utilizing a total of nine magnetic relays connected to three trip solenoids. In Triple Modular Redundancy systems, all nine relays are employed to provide redundancy and fail-safety, whereas in simpler configurations, only three relays are utilized for efficient operation.

    Equipped with state-of-the-art flame detection technology, the control board monitors eight Geiger-Mueller flame detectors, ensuring continuous and accurate measurement of combustion processes. This feature is crucial for maintaining optimal turbine operation and preventing potential hazards.

    Crafted from high-quality materials and featuring an ergonomic design, the IS200VTURH1BAC Control Board is not only durable but also user-friendly, facilitating quick installation and easy maintenance. It is compatible with a variety of hardware platforms, making it a versatile addition to any industrial control system.
