Module Type:Profibus DPV1 Master

Product ID:MVI69-PDPMV1

Compatibility:Single-slot, 1769 backplane compatible

Memory Access:Input/Output module with access to processor memory

Data Transfer:Ladder Logic for data transfer between module memory and processor controller tags

Configuration:Sample ladder file included, configuration data from ProSoft Configuration Builder Software

Network Definition:Network definition provided by software for PROFIBUS network configuration

Communication Parameters:Flexible baud rate (110 to 115K), stop bits (1 or 2), data size (7 or 8 bits), parity (None, Even, Odd)

Timing Delays:Variable RTD timing delays (0 to 65535 milliseconds)

Floating Point Support:Supported, configurable for Enron, Daniel, and other implementations

Power Supply:220V AC power supply

Operating Frequency:30kHz

Certification:Certified product

Series Designation:Extended Module

    The Prosoft MVI69-PDPMV1 PROFIBUS DPV1 Master is engineered to enhance productivity and streamline operations within complex industrial control systems. Its compatibility with the 1769 backplane ensures a robust connection, allowing seamless integration with existing CompactLogix systems.

    Access to processor memory enables efficient data transfer, optimizing the flow of information between the master and the system components. Utilizing Ladder Logic for data exchange provides a straightforward approach to programming and maintenance, ensuring ease of use for operators and technicians alike.

    Configuration data is easily obtained through the ProSoft Configuration Builder Software, providing flexibility and customization options for your specific network requirements. This module is designed to facilitate the definition of PROFIBUS networks, ensuring reliable and efficient communication.

    The inclusion of AOI (Application-Oriented Interface) ensures compatibility with a wide range of applications, enhancing its versatility across various industries. Whether you're looking to improve efficiency, reduce downtime, or simply integrate a new system component, the Prosoft MVI69-PDPMV1 PROFIBUS DPV1 Master offers a comprehensive solution tailored to meet your needs.

    With direct access to module data and status through RSLogix 5000 controller tags and UDTs, monitoring and troubleshooting become more streamlined, reducing the time required for maintenance tasks. Additionally, the ability to emulate Modbus Master or slave devices on each individually-configurable application port provides further flexibility and control over your automation processes.
