Number of Channels:16

Analog Input Range:0 to 10V / 4 to 20mA

Sampling Rate:1 kHz

Signal Conditioning:Temperature compensated, common mode rejection ratio > 90 dB

Operating Temperature:-25°C to +60°C

Input Resistance:High, ensuring minimal loading effects

Power Consumption:Low, optimized for efficient operation

Communication Interface:Modular design for easy integration

Dimensions:Compact size for space-saving installation

    The ABB AI523 is an advanced 16-channel analog input module specifically tailored for industrial environments requiring high accuracy and robust data acquisition capabilities. With its wide input range and exceptional precision, it seamlessly integrates into complex control systems to enhance operational efficiency.

    Equipped with high-speed sampling at 1 kHz, the AI523 ensures real-time data processing, making it ideal for applications demanding quick response times and precise measurements. Its compatibility with leading communication protocols like DeviceNet, CANopen, and EtherCAT facilitates seamless integration with a wide array of industrial automation systems.

    Designed for operation in extreme conditions (-20°C to +70°C), this module withstands harsh environments commonly encountered in manufacturing plants, ensuring reliable performance throughout its lifecycle. It meets stringent international safety and compliance standards, including CE, UL certifications, and adherence to IEC 61131-2 guidelines for programming languages in control systems.

    Featuring compact dimensions (105mm x 150mm x 115mm) and weighing 1.2kg, the AI523 is easy to install and integrate into existing machinery without compromising on functionality. Its lightweight yet sturdy design makes it suitable for both new installations and retrofits.

    For industries seeking to optimize their processes through enhanced data collection and analysis, the ABB AI523 offers unparalleled value. Whether in automotive, chemical, food & beverage, or any other sector where precision and reliability are paramount, this module is an indispensable tool for advancing automation capabilities.
