Model Type:Digital Output Module

Model Number:6ES7522-5HH00-0AB0

Manufacturer:SIEMENS

Net Weight:0.339 kg

Packaging Dimension:14.90 x 15.30 x 4.30 cm

Power Supply:230V 1 phase / 460V 3 phase

Channels:8x24V DC

Current Rating:0.5 A per channel

Max. Frequency:600 Hz

Protection Level:Complete

Diagnosis:Short-circuit to L+, Ground, Wire Break, Supply Voltage

Dimensions:Standard DIN rail mount

Connectivity:Single-channel diagnostics, front connector (screw terminals or push-in)

Lifecycle:Active (PM300)

    This SIEMENS digital output module is engineered for precision and reliability, featuring 8 channels for versatile control applications.

    The robust design ensures compatibility with SIMATIC S7-1500 systems, facilitating seamless integration and enhanced system performance.

    Equipped with an integrated EMI filter for 230V single phase and 460V three phase, it minimizes interference and ensures stable operation.

    Each channel supports a current rating of 0.5A at 24V DC, providing ample power for most industrial actuators and sensors.

    Featuring single-channel diagnostics, the module offers real-time monitoring and protection against common electrical faults, ensuring system uptime and safety.
