Model:2098-DSD-020X

Brand:Allen-Bradley

Weight:2.1 kg (4.6 lbs)

Dimensions:98.1mm x 32.77mm x 65.02mm

Input Voltage (AC):100-240VAC rms, 1-Phase

Nominal Input Current:18 A, RMS

Output Voltage (AC):100-240VAC

Frequency Range:0-400 Hz

Continuous Output Power:1kW

Continuous Output Current:1A

Intermittent Output Current:30A

Power:1.0 kW

Bus Capacitance Rating:1880 µF

Bus Overvoltage:400 Vdc

Energy Absorption Capability:125 Joules @ 115VAC, 51 Joules @ 230VAC input

    Introducing the Allen-Bradley 2098-DSD-020X Digital Servo Drive, the pinnacle of precision and efficiency in industrial automation. Designed for seamless integration with Allen-Bradley's Kinetix Servo Motor series, this ultra-durable drive ensures smooth motion control and precise positioning, making it an indispensable tool in any manufacturing line.

    Featuring a compact size of 2.1kg (4.6lbs) and dimensions of 98.1mm x 32.77mm x 65.02mm, the 2098-DSD-020X offers unparalleled versatility, fitting seamlessly into a wide range of equipment configurations without compromising on performance.

    Equipped with a robust design that supports a nominal input current of 18 A, rms, and 100 Ampere for series A and B, 20 Ampere for series C at 230VAC (0-pk), this drive ensures reliable operation across various industrial environments.

    The 2098-DSD-020X boasts an impressive energy absorption capability of 125 Joules when operated at 115VAC and 51 Joules at 230VAC input, safeguarding against sudden voltage surges and ensuring system integrity under challenging conditions.

    With its built-in indexing capability, the drive simplifies complex motion sequences, allowing users to store and select pre-configured servo motor movements from the drive’s memory, enhancing productivity and reducing setup times for repetitive tasks.
