Brand:ABB

Model:PWD86 57087234

Module Type:Watchdog Timer

Operating Temperature:-20°C to +60°C

Power Consumption:Max. 250mW (Typ.)

Relay Output:1 SPST Relay

Input Voltage:10VDC to 30VDC

Output Voltage:24VDC @ 10mA

Response Time:10ms (Typ.)

Size:Compact DIN Rail Mountable

Material:Robust Enclosure

Certifications:CE, UL, CSA

    The ABB PWD86 57087234 Industrial Watchdog Timer is engineered with advanced monitoring capabilities to detect and prevent unexpected shutdowns or malfunctions in industrial automation systems. Its high-speed monitoring function ensures immediate response to system anomalies, thereby maintaining uninterrupted operations and enhancing overall system reliability.

    Equipped with a versatile single NO contact output, this timer offers flexible integration options, making it suitable for various applications in manufacturing, process control, and automation environments. Its adjustable monitoring frequency allows users to customize the timer to suit specific system requirements, ensuring optimal performance and responsiveness.

    With an extensive operating temperature range of -20°C to +70°C and a storage temperature range of -40°C to +85°C, the PWD86 57087234 Watchdog Timer is designed to withstand harsh industrial conditions, ensuring reliable operation under diverse environmental challenges.

    Featuring a protection class of IP20, this device is protected against solid foreign objects larger than 1mm, safeguarding internal components from dust and debris. Its compact size (125mm x 90mm x 36mm) and lightweight design (0.1kg) facilitate easy installation and maintenance in confined spaces without compromising on functionality.

    For enhanced user convenience and system flexibility, the ABB PWD86 57087234 Watchdog Timer comes with a reset time range adjustable from 1ms to 3600 seconds. This feature allows for precise timing control, enabling operators to tailor the watchdog's response time to match the specific needs of their industrial processes.
