Product Type:Network Controller

Model Number:X20BC8084

Fieldbus Compatibility:EtherNet/IP, Modbus/TCP, Modbus/UDP

Integrated Switch Ports:3

Auto-Configuration:Yes, for I/O Modules

Configuration Method:Scanned by Master

Web Interface:Available for Configuration

DHCP Capability:Yes

I/O Cycle Configuration:0.5 – 4 ms

Minimum Fieldbus Cycle Time:1 ms

Power Consumption:Bus: 2 W

Max Cable Length:100 m between 2 stations

Transfer Rate:10/100 Mbit/s

Status Indicators:Module Status, Network Status, Bus Function

Certification:Industry Standard Compliant

    The B&R X20BC8084 BUS CONTROLLER is engineered for industrial automation tasks, featuring a compact design that maximizes space efficiency without compromising performance. It is equipped with an integrated 3-port switch, designed for efficient cabling and easy installation in various industrial settings.

    This state-of-the-art controller offers auto-configuration for I/O modules, significantly reducing setup times and enhancing productivity. It can be easily configured by the master using a scanner, ensuring seamless integration into existing systems.

    Accessible via a web interface, users can leverage the controller's full capabilities for customization and management, including DHCP for dynamic IP addressing and a configurable I/O cycle to tailor performance to specific needs.

    With a minimum fieldbus cycle time of 1 millisecond, the X20BC8084 BUS CONTROLLER ensures fast data transfer and responsive control systems, making it ideal for high-speed applications in manufacturing, robotics, and process control industries.

    Equipped with robust status indicators, the controller provides real-time feedback on module status, network health, and bus functionality, enabling proactive maintenance and system optimization. Its low power consumption and compatibility with industry-standard protocols ensure energy efficiency and interoperability with a wide range of devices.
