Model Type:ControlLogix Communication Module

Manufacturer(s):Allen Bradley

Power Supply:3 MA at 24 VDC

Mounting:Chassis

Communication Speed:10/100 Mbps

Communication Protocol:Ethernet/IP Bridge

Enclosure:Open Type

Connection Cables:802.3 compliant shielded or unshielded twisted pair

Temperature Rating:0 – 60 DEG C

Power Dissipation:5.1 W

Isolation:30 V continuous

Environmental Conditions:5 – 95% non-condensing relative humidity

Vibration:2 G

Shock:30 G

Interface:Ethernet

USB Port:Not applicable

    Engineered for reliability and efficiency, the Allen-Bradley ControlLogix 1756-EN2T/D Communication Module is an essential component for advanced automation systems. It seamlessly integrates with ControlLogix platforms, providing seamless communication between various devices and enabling efficient data exchange.

    This module supports a wide range of applications across manufacturing, food processing, and other industries requiring high-speed, reliable communication. Its open-type enclosure ensures easy installation and maintenance, while the 802.3 compliant cables offer flexibility in connection options.

    With support for Ethernet/IP protocols, the 1756-EN2T/D module bridges the gap between different network infrastructures, enhancing interoperability and system scalability. The inclusion of radiated RF suppression ensures robust performance even in environments with high electromagnetic interference.

    Designed with user convenience in mind, the module's intuitive interface facilitates quick setup and configuration, allowing technicians to focus on critical tasks. Its compatibility with ControlNet A/B and ControlNet A to ControlNet B interfaces ensures seamless integration with existing network architectures.

    Built to withstand challenging operational conditions, this module operates within a temperature range of 0 to 60°C, making it suitable for use in diverse industrial settings. Its power dissipation of 5.1W and continuous isolation rating of 30V guarantee optimal performance and safety, ensuring minimal downtime and maximum productivity.
