Processor Type:High-performance microprocessor

Operating System:Customized ABB PLC OS

Memory Capacity:128 KB of user memory

Input/Output Channels:24 digital input channels, 16 digital output channels

Ethernet Interface:10/100 Mbps Ethernet

Power Supply:12 to 24 VDC

Dimensions (WxHxD):100 mm x 165 mm x 118 mm

Operating Temperature Range:-10°C to +55°C

Enclosure Protection Rating:IP20

Protocol Compatibility:MODBUS TCP/IP, DeviceNet

    The ABB PM564-TP-ETH Logic Controller is an essential component for modern industrial control systems, providing a robust platform for efficient data processing and communication. Its compact design allows for easy integration into existing setups without compromising performance.

    Featuring a high-speed processor and ample memory, this controller ensures quick response times and smooth operation even in complex, demanding environments. Its Ethernet interface facilitates seamless connectivity with other devices and systems, enhancing overall system reliability.

    With its versatile input/output configurations, the PM564-TP-ETH can accommodate a wide range of sensors and actuators, making it suitable for applications across various industries. Whether it's monitoring temperature, pressure, or controlling motor speeds, this controller offers precise control and accuracy.

    Designed with durability in mind, the IP20 enclosure protects against dust and minor impacts, ensuring reliable operation in industrial settings. It is capable of operating within a broad temperature range (-25°C to +60°C), making it suitable for use in diverse environments.

    Installation and setup are streamlined with intuitive programming software, allowing engineers and technicians to configure and optimize the controller according to specific application requirements. This ease of use, combined with its advanced features, makes the ABB PM564-TP-ETH a top choice for enhancing productivity and efficiency in industrial automation.
