Product Type:Bus Controller

Model Number:X20BC8084

Technology Used:EtherNet/IP

Number of Ports:3

Connection Capacity:Integrated 3-port switch for efficient cabling

Auto-Configuration:I/O modules auto-configurable by scanner (master)

Web Interface:DHCP capable

Configurable I/O Cycle:0.5 – 4 ms

Minimum Fieldbus Cycle Time:1 ms

Power Consumption:Bus: 2 W

Cable Length:Max. 100 m between 2 stations (segment length)

Transfer Rate:10/100 Mbit/s

    The B&R X20BC8084 Bus Controller is an indispensable tool for industrial automation, featuring advanced EtherNet/IP technology to enhance connectivity and performance.

    With its integrated 3-port switch, this controller optimizes cabling and reduces complexity in network configurations, ensuring efficient data flow.

    Auto-configuration of I/O modules simplifies the setup process, allowing for quick and easy integration of peripheral devices without extensive manual configuration.

    Accessed via a web interface, users can manage and monitor their system remotely, increasing operational efficiency and reducing downtime.

    DHCP capability ensures seamless device discovery and network setup, streamlining deployment processes.

    Flexible configurable I/O cycle times offer customization options to match specific application requirements, optimizing response times and performance.

    The minimum fieldbus cycle time of 1 ms ensures rapid data processing, critical for real-time applications in manufacturing and automation.
