Product Type:Encoder Board

Model:AB 1336-L5

Application Type:Less Encoder Configuration

Power Consumption:≤ 3.5 W

Operating Temperature Range:-25°C to +70°C

Input Voltage:24 VDC

Communication Interface:RS-485 Modbus RTU

Dimensions (WxHxD):97mm x 110mm x 34mm

Weight:0.2kg

    The AB 1336-L5 Encoder Board is designed for high-precision position measurement and feedback control in industrial automation systems. It features a robust, compact design suitable for harsh industrial environments.

    Equipped with a high-resolution encoder, this board ensures accurate position tracking and smooth operation in machinery, robotics, and process control applications. Its wide input voltage range makes it compatible with various power supplies found in industrial settings.

    With its reliable RS-485 communication interface, the AB 1336-L5 Encoder Board seamlessly integrates with PLCs, motion controllers, and other industrial equipment, facilitating easy setup and maintenance.

    Featuring an IP65 rated enclosure, this board is dustproof and protected against water splashes, ensuring continuous operation even under challenging conditions. The M12 connector provides a secure and durable connection point.

    The board's low power consumption minimizes energy usage, contributing to overall system efficiency. Additionally, its compatibility with a wide range of industrial protocols enhances its versatility and adaptability across different automation systems.
