Model Type:Redundant Bridge Module

Model Number:1756-CNBR

Manufacturer:Allen-Bradley

Communication Protocol:ControlNet

Number of Channels:2

Current Rating:Drawn: 970 MA at 5.1 VDC, 1.7 MA at 24 VDC

Isolation:30 V (Continuous)

Enclosure:Open Type

Rfi Suppression:Radiated: 10 V/M with 1 KHZ Sine-Wave 80% AM from 80 – 2000 MHz

Conducted Emission:10 VRMS with 1 KHZ Sine-Wave 80% AM from 150 KHZ – 80 MHz

Temperature Range:-40°C to +70°C

Weight:0.494 lb

Packaging Dimension:5.197 x 5.827 x 2.008 inches

    The Allen-Bradley 1756-CNBR ControlNet Redundant Bridge Module is engineered for unparalleled reliability in industrial automation environments, providing redundant communication paths for increased system availability and uptime.

    Featuring dual channels, this module ensures robust data transmission even under adverse conditions, critical for applications requiring high reliability and fault tolerance.

    Equipped with advanced isolation technology, it safeguards against electrical interference, ensuring secure and stable data exchange between ControlNet networks.

    Designed for integration into Allen-Bradley ControlLogix systems, this module seamlessly connects ControlNet A and B networks, facilitating efficient data flow and control within complex automation setups.

    Manufactured with durability and longevity in mind, the 1756-CNBR is a trusted choice for industries demanding high-performance and dependable automation solutions.
