Measurement Resolution:16-bit

Sampling Frequency:Up to 1 kHz

Analog Input Range:-10 V to +10 V

Digital Input Channels:8

Communication Protocol:DeviceNet, EtherCAT, CANopen

Power Supply Voltage:10 VDC to 30 VDC

Operating Temperature:-20°C to +60°C

Storage Temperature:-40°C to +85°C

    The ABB DSQC562 3HAC16014-1/07 Serial Measurement Unit is engineered with high accuracy and reliability, making it an ideal choice for demanding industrial environments. It offers a robust interface for seamless integration with ABB's advanced programmable logic controllers (PLCs), ensuring efficient data management and control.

    Equipped with 8 high-resolution analog input channels, this unit can accurately measure various physical quantities such as temperature, pressure, and flow rates, providing real-time data for process optimization and monitoring. Its digital input/output channels facilitate flexible control logic implementation, enhancing system responsiveness and efficiency.

    Designed for operation within a wide temperature range (-20°C to +60°C), the DSQC562 3HAC16014-1/07 is built to withstand harsh industrial conditions, ensuring reliable performance under diverse environmental challenges.

    With its support for DeviceNet and EtherCAT communication protocols, this measurement unit seamlessly integrates into complex network architectures, allowing for real-time data exchange and control over a wide range of devices and systems. This feature is particularly advantageous in multi-vendor environments where interoperability is crucial.

    The DSQC562 3HAC16014-1/07 is equipped with relay outputs rated at 5A at 24V DC, providing a powerful means for controlling external devices or actuators. This capability ensures that the unit can effectively manage various operational tasks within industrial processes.
