Type:Rotary Encoder

Resolution:13 bits

Max. Count:8,192 Counts

Signal Output:Push-Pull (Open Drain)

Operating Voltage:DC 5V ±10%

Operating Current:≤ 3.0mA

Operating Temperature Range:-20°C to +70°C

Rotation Speed Range:≤ 1000 rpm

Diameter:36mm

Material:Aluminum

Connectivity:2-wire connection

    The OMRON E6H-CWZ3X Encoder is engineered for seamless integration into complex industrial machinery, providing unparalleled performance in terms of accuracy and robustness.

    With its compact design and aluminum housing, this encoder ensures durability and resistance against harsh environments, making it ideal for various industrial applications.

    Featuring a 13-bit resolution, the E6H-CWZ3X Encoder offers exceptional precision, enabling precise measurement and control of rotational movements.

    Equipped with a push-pull (open drain) signal output, the encoder facilitates efficient communication with other components in your system, ensuring smooth operation and reliable data transmission.

    Operating within a wide temperature range (-20°C to +70°C), the E6H-CWZ3X Encoder maintains its performance under varying environmental conditions, ensuring continuous functionality in diverse industrial settings.
