NI PXI-2546 Switch Module
NI PXI-2546 High-Density Multiplexer Switch Module
About Guizhou Yuanmiao
As global industrial automation specialists, we provide comprehensive solutions covering 30+ top brands including NI, Siemens, ABB, and Schneider. Our technical team offers 24/7 cross-brand compatibility consultation.
Product Highlights
- 128-Channel matrix configuration for complex test systems
- 5μs ultra-fast switching speed
- 300V CAT II overvoltage protection
- Hot-swappable PXI Express compatibility
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | National Instruments |
| Model | PXI-2546 |
| Switching Type | SPDT Matrix |
| Contact Rating | 2A @ 250VAC |
| Dimensions | 3U PXI Module (160×100×30mm) |
Typical Applications
- Automated test systems for aerospace components
- Multi-sensor data acquisition in energy systems
- Production line testing solutions
Compatible Accessories: SHC68-68-EPM cables, PXIe-1062Q chassis, TB-2646 terminal block
Our Service Commitment
✅ 365-day warranty with replacement guarantee
✅ Global logistics support (DDP/DDU options)
✅ On-demand technical documentation service
