Product Overview

• 20-750-ENC-1 is an optional encoder module for PowerFlex 750 series drives
• Provides incremental encoder feedback for closed loop speed and position control
• Compatible with PowerFlex 753, 755, 755TL and 755TR AC drives

• Product status: Active, available for new installation and replacement

•


Core Features

• Single channel incremental encoder with A/B/Z quadrature signals
• Supports 5VDC differential RS-422 and single ended TTL signals
• Maximum input frequency up to 1 MHz
• Built in LED indicators for power, fault and signal status
• Electrical isolation and over current protection design

• Easy installation on drive expansion slots

Technical Parameters

• Brand: Allen Bradley Rockwell Automation
• Part Number: 20-750-ENC-1
• Series: PowerFlex 750
• Encoder Type: Incremental
• Encoder Supply: 5-15VDC, 10mA
• Operating Temperature: 0°C ~ 40°C
• Storage Temperature: -40°C ~ 85°C
• Relative Humidity: 5% to 80% non-condensing
• Weight: 0.25kg

• Certifications: CE, UL, CSA, RoHS

•


Applications

• Closed loop vector control and positioning for AC drives
• Conveyors, winding machines and machine tool spindle control
• Motion control in heavy industrial environments

• System expansion and retrofit of PowerFlex 750 series drives

•
