1771-OBDS Allen Bradley 32-channel DC digital output module 24V 2A per channel 1771 PLC5 refurbished 12 month warranty

Product Overview

• 1771-OBDS is a 32-channel DC digital output module for Allen Bradley 1771 PLC5 series
• High-density output, single-slot installation in 1771 chassis

• Product status: Discontinued, available as refurbished and surplus units

•


Core Features

• 32 output channels, 2A per channel resistive load
• Nominal 24VDC output, logic input 4.0–5.5VDC
• Compatible with 1771 backplane, direct plug-in
• LED status indicators for each channel

• Short-circuit and overcurrent protection

Technical Parameters

• Brand: Allen Bradley Rockwell Automation
• Part Number: 1771-OBDS
• Series: 1771 PLC5
• Channel Count: 32
• Output Voltage: 24VDC nominal
• Output Current: 2A per channel
• Backplane Current: 400mA @5VDC
• Operating Temperature: 0°C~60°C
• Weight: 0.28kg

• Dimensions: 121×43×127mm

•


Applications

• Industrial automation digital control, driving solenoids, relays, lamps
• PLC5 system expansion, high-density I/O projects
• Manufacturing, process control, packaging machinery

• Legacy 1771 system maintenance and retrofit

•


Our Advantages

• Full functional testing before delivery
• Sufficient stock and fast global shipping
• Competitive price with reliable quality
• 12 month warranty and technical support
