DS200ADGIH1AAA GE Mark V Speedtronic Auxiliary Interface Board Discontinued Refurbished & New Surplus Stock

Short Description:

DS200ADGIH1AAA GE auxiliary interface PCB for Mark V turbine control system, sig

Send email to us

Product Detail

DS200ADGIH1AAA GE auxiliary interface PCB for Mark V turbine control system, signal conditioning & IO expansion board, full tested refurbished with 12-month warranty, spot available

Product Overview

PN：DS200ADGIH1AAA | Brand：GE General Electric | Series：Mark V Speedtronic Turbine Control System
It is a dedicated auxiliary signal interface board, realizing signal conversion, conditioning and wiring bridge between main CPU board and field analog/digital sensors & actuators
Original OEM production stopped, available with new surplus, used and fully calibrated refurbished spare parts for unit maintenance replacement

Core Features

Equipped with 1×40-pin +1×6-pin external signal connectors, 60 configurable jumper pins for flexible signal definition, multiple onboard test points for onsite troubleshooting
Built-in signal isolation & filter circuit to restrain industrial field electromagnetic interference, stabilize analog/digital signal transmission
Standard rack plug-in installation design, fixed by four positioning screws matching control cabinet card slot frame
Integrates multi-channel AI/DO signal processing circuit for system IO capacity expansion of gas/steam turbine control rack

Technical Parameters

Part No:DS200ADGIH1AAA
Dimension:203mm(W)×152mm(L)(8inch×6inch)
Working Power:Derived from Mark V backplane power supply 24VDC
Operating Temp:-40℃ ~ +70℃, humidity 5%~95% non-condensing
Approx Weight:0.41kg

Applications

Power plant steam/gas turbine Mark V control cabinet spare replacement & system overhaul retrofit
Petrochemical, metallurgy, gas-fired generator set legacy GE turbine control system maintenance
Heavy industry old Speedtronic DCS cabinet signal channel repair and upgrade project
