DS200TCQAG1BHF GE Mark V Speedtronic TCQA Analog I/O Board Discontinued Refurbished & New Surplus In Stock

Short Description:

DS200TCQAG1BHF GE TCQA analog input/output PCB for Mark V TMR turbine control sy

Send email to us

Product Detail

DS200TCQAG1BHF GE TCQA analog input/output PCB for Mark V TMR turbine control system, full tested refurbished spare with 12-month warranty, fast global delivery available

Product Overview

PN：DS200TCQAG1BHF | Brand：GE General Electric | Series：Mark V Speedtronic Turbine Control, TCQA Analog I/O Card
Core function: collect field analog signals from temperature/pressure/flow transmitters, signal conditioning and scaling, output precision analog drive signal to servo valves & regulating actuators
Adopts RST triple modular redundant(TMR) design, three identical boards installed in R/S/T core for fault-tolerant turbine control; original production discontinued, supply tested refurbished & new surplus modules

Core Features

Equipped with 4×34pin + 2×40pin external signal connectors, onboard 6 status LED indicators and configurable jumper pins for channel definition
Built-in isolation & filter circuit to suppress industrial EMI, ensure stable 4-20mA/0-10V analog signal transmission
Standard single-slot plug-in structure, fixed with six mounting screws matching Mark V control cabinet rack
16-channel analog input +16-channel analog output layout for turbine parameter acquisition and fuel/steam valve closed-loop control
Specially optimized for TMR voting control logic to avoid unit trip caused by single board failure

Technical Parameters

Part No:DS200TCQAG1BHF
Overall Dimension:280×212×25mm
Power Source:Supplied via Mark V backplane, Max power consumption 194W
Signal Range:4–20mA / 0–10VDC standard industrial analog signal
Operating Temp:-30℃ ~ +75℃, 5%~95%RH non-condensing
Approx Net Weight:0.98kg

Applications

Thermal power plant gas/steam turbine Mark V TMR control cabinet spare replacement & overhaul maintenance
Petrochemical, metallurgy heavy-duty turbine unit legacy DCS system retrofit and fault repair
Cogeneration plant, industrial large compressor original GE control rack spare parts upgrade
