Product Overview

• PN：HE693STP104AX | Brand：Horner Electric / GE Fanuc | Series：Series 90-30 PLC System
• It is dedicated single-axis programmable stepper motion control module, serving as pulse indexer to connect stepper driver, limit switch and position feedback encoder, generates step/direction pulse for precise stepping motor positioning control
• Original OEM production discontinued, supplied with new surplus, pre-tested used & refurbished spare parts for old equipment maintenance replacement

Core Features

• Max pulse output frequency up to 50kHz, support micro-step driver matching for stable low-vibration motor operation
• Built-in home search, soft limit/hard limit protection, position closed-loop via external quadrature encoder feedback
• Standard single-slot rack plug-in design, directly plug into GE 90-30 PLC backplane for bus communication
• Onboard status LED indicators for power, running, fault alarm and channel troubleshooting
• Flexible programming via PLC ladder logic to set positioning distance, speed, acceleration and indexing sequence

Technical Parameters

• Part No:HE693STP104AX
• Working Power:24VDC from PLC backplane
• Max Step Output:50kHz single-axis pulse+direction signal
• Encoder Input:Quadrature AB phase incremental encoder interface
• Operating Temp:-20℃ ~ +65℃, 5%~95%RH non-condensing
• Approx Net Weight:0.35kg
• Compatible Rack:GE Fanuc Series 90-30 CPU base rack

Applications

• CNC cutting equipment, automatic feeder, conveyor positioning, packaging machinery retrofitting
• Printing, textile, metal processing old automation production line PLC spare replacement
• Laboratory precision positioning equipment, automated assembly line stepping control cabinet maintenance

Our Advantages

• Full function aging & pulse output calibration test before delivery
• 12-month global warranty for refurbished modules
• DHL/Fedex fast door-to-door international shipment
• Technical support for wiring, parameter setting and PLC program debugging
