Product Overview

• PN：IC670MDL640｜Brand：GE Fanuc/Emerson｜Series：FieldControl Genius Distributed I/O
• Core：16-point DC sink digital output module to drive field relays, solenoid valves and indicator lights, used together with IC670GBI002 or IC670CPU350 to construct remote Genius I/O station

• Original production discontinued, supply new surplus and fully tested refurbished spare parts for obsolete equipment maintenance

•


Core Features

• 16 sink-type output channels grouped in single common terminal, external 24VDC field power required
• Independent status LED for each output channel to display on/off working state
• Hot swappable structure, directly install and remove on all IC670CHS series terminal bases without power cut
• Built-in surge absorption circuit to protect internal chip from inductive load reverse electromotive force

• Over-current short-circuit protection per group to avoid module burnout caused by field wiring fault

•


Technical Parameters

• Part No: IC670MDL640
• Rated field voltage: 24VDC, operating range 18~30VDC
• Single channel continuous output current: 0.5A
• Total module max output current: 8A
• Switch response time: typical 0.5ms
• Backplane power consumption: 90mA @5VDC
• Operating temp:0℃~+55℃; Storage:-40℃~+85℃, RH5%~95% non-condensing
• Net weight:0.26kg
• Dimension:202×108×52mm

• Certification:UL, CE, CSA

•


Compatibility

• Compatible with IC670CHS001/CHS002/CHS101 all terminal bases
• Cooperate with IC670GBI002 bus interface module and IC670CPU350 standalone CPU

• Connect to GE Series90-30/RX3i host PLC through Genius fieldbus

•


Applications

• Power plant, petrochemical, water treatment old remote I/O cabinet spare replacement

• Metallurgy, packaging, textile production line legacy FieldControl control system renovation

•


Our Advantages

• Full channel load aging test before delivery
• 12-month global warranty for refurbished products
• DHL/Fedex global door-to-door express delivery
• Professional wiring and station configuration technical support
