IC693APU300K GE Series90-30 High Speed Counter Module Obsolete In Stock

Short Description:

IC693APU300K GE Fanuc high speed counter module for Series90-30 PLC,12 high-spee

Send email to us

Product Detail

IC693APU300K GE Fanuc high speed counter module for Series90-30 PLC,12 high-speed input+4 preset output,max 80kHz counting,offload CPU pulse computation,full tested with 12-month warranty for old equipment spare replacement

Product Overview

PN：IC693APU300K｜Brand：GE Fanuc/Emerson｜Series：Series90-30 PLC System
Core：Independent high-speed counter coprocessor module,offloads high-frequency pulse counting from main CPU,supports encoder,proximity switch,magnetic pickup signal collection & preset automatic output control
OEM discontinued,supply new surplus & fully calibrated refurbished spare parts for legacy automation retrofit & maintenance

Core Features

12-point positive logic high-speed input,2 configurable input modes:5VDC /10~30VDC,channel isolation 250VAC RMS
4-point positive logic preset output,each counter owns 2 preset values for auto-trigger output without CPU real-time intervention
Three working counting modes:4 single up/down counter;2 AB quadrature dual-direction counter;1 differential calculation counter
Dual filter option:2.5μs high-frequency filter /12.5ms low-frequency anti-jitter filter,adapt different field pulse signals
Multiple LED indicators:Module OK,Config OK,Field Power,individual I/O status LED for quick fault diagnosis

Technical Parameters

Part No:IC693APU300K
Max counting frequency:80kHz high speed;minimum 20Hz low speed
Input specification:5VDC(ON≥3.25V/OFF≤1.5V);10~30VDC(ON≥8V/OFF≤2.4V)
Output spec:10~30VDC max 0.5A/point;5VDC max20mA/point;total output with 3A fuse protection
Backplane consumption:250mA @5VDC
Operating temp:0℃~+60℃;Storage:-40℃~+85℃,RH5%~95% non-condensing
Net weight:0.23kg｜Dimension:127×127×51mm
Cert:UL,CE,CSA certified

Compatibility

Single-slot installation for all standard Series90-30 backplane racks & full-range CPU units
Match all Series90-30 discrete/analog modules to build complete position/speed control cabinet

Applications

CNC machinery,packaging equipment,printing line encoder position & speed monitoring
Petrochemical,water treatment flow meter pulse acquisition,rotating equipment speed measurement
Metallurgy conveying line part counting & preset cut-off automatic control
