Product Overview

• PN: 330104-00-05-10-02-00
• Brand: Bently Nevada (Baker Hughes)
• Series: 3300XL Non-Contact Proximity Transducer System
• Type: 8mm Linear Range Straight Exit Probe

• Function: Non-contact eddy current sensor converting gap distance between probe tip and metal target into analog voltage signal. Cooperates with supporting proximitor to transmit signals to monitoring modules, realizing real-time measurement of shaft radial vibration and axial thrust displacement, and triggering alarm and interlock protection when values exceed preset limits.

•


Suffix Definition

• 330104: Base model with 8mm effective measuring range
• 00: Straight cable outlet
• 05: Integral cable length 5 meters
• 10: Standard mounting thread specification
• 02: Normal temperature resistant cable

• 00: Standard general version without area-specific customization

•


Core Features

• 0~8mm linear measurement range, the most common specification for turbomachinery bearing housing monitoring
• Straight outlet structure, fits standard reserved installation holes of most bearing assemblies
• 75Ω triaxial shielded cable with strong anti-interference ability against industrial electromagnetic noise
• Stainless steel probe housing with good mechanical strength and corrosion resistance
• Double sealing structure, stable operation in oily, damp and dusty equipment internal environment
• Fixed resistance parameter, convenient for on-site multimeter inspection to judge probe integrity

• Designed in accordance with API 670 standard for machinery protection sensors

•


Technical Specifications

• Effective Linear Range: 0 ~ 8 mm
• Integral Cable Length: 5 m
• Probe Mount Thread: 3/4-16 UNF
• Nominal Probe Resistance: 7.9Ω ± 0.5Ω
• Operating Temperature: -35℃ ~ +177℃
• Minimum Cable Bend Radius: 25 mm
• HS Code: 85437090
• Certifications: CE

• Product Status: Mass production available, brand new original sealed and fully tested spare parts in stock

•


Compatibility

• Matching Accessories: Corresponding 3300XL proximitor oscillator and extension cables
• Compatible Monitoring Modules: 3500/40M, 3500/42M, 1900 series standalone monitors
• Applicable Equipment: Steam turbines, gas turbines, generators, compressors, blowers and large industrial pumps

• Applicable System: Complete 3500 TSI turbomachinery protection rack system

•


Application

• Radial vibration monitoring of rotating shafts for generator sets and industrial compressors in power and petrochemical plants
• Axial displacement detection of thrust bearings to avoid rotor collision and equipment damage
• Spare replacement and system renovation for legacy 7200 and early 3300 series monitoring systems
• Condition monitoring of auxiliary rotating equipment in metallurgy and water treatment industries
