Product Overview

• PN: V4550220-0100
• Brand: ABB
• Series: Epic II ESP dedicated control system
• Type: Electrostatic Precipitator Integrated Controller Module

• Function: Central control core of industrial electrostatic dust removal equipment. It collects on-site flue gas condition, high-voltage rectifier operating parameters, equipment temperature and switch status signals, automatically adjusts the output voltage and current of the dust removal power supply according to load conditions, optimizes dust collection efficiency. It uploads real-time running data, working curves and fault records to upper DCS or host computer through standard industrial communication, and triggers alarm and interlock protection for overcurrent, overvoltage, short circuit and equipment abnormal faults to ensure safe and stable operation of the whole dust removal system.

•


Core Features

• Built-in complete I/O resource: 8-way digital input, 8-way digital output, 4-way analog input, 2-way 4-20mA analog output, rich wiring terminals to meet field signal access without additional expansion modules
• Supports Modbus TCP/IP and Profibus DP dual mainstream communication protocols, compatible with factory centralized control system networking access
• Equipped with local parameter setting button and status indicator lamp, on-site commissioning and parameter modification can be completed without upper computer
• Built-in fault self-diagnosis logic, automatically record fault codes and historical events, convenient for later maintenance and troubleshooting
• Aluminum alloy integrated sealed casing, internal circuit conformal coating, strong anti-electromagnetic interference, adapt to high dust, vibration and temperature fluctuation harsh industrial environment
• Multiple protection mechanisms including overvoltage, overcurrent, short circuit and power loss memory, avoid equipment damage caused by abnormal working conditions

• Panel mounting and wall-mounted two installation modes, flexible layout inside dust removal control cabinet

•


Technical Specifications

• Working Power Supply: 24VDC
• Analog Output Standard Signal: 4~20mA
• Ambient Operating Temperature: -20℃ ~ +70℃
• Shell Protection Grade: IP20
• Communication Mode: Modbus TCP/IP, Profibus DP
• Net Weight: Approximately 1.36kg
• HS Code: 85372090
• Certification: CE

• Product Status: Original discontinued spare part, brand new original sealed and fully tested refurbished products available in stock

•


Compatibility

• Matching Devices: ABB series high-voltage rectifier transformers for electrostatic precipitators, field pressure/temperature transmitters, auxiliary contactors and alarm components
• Upper Control System: ABB 800xA DCS, third-party PLC and centralized monitoring host

• Applicable Equipment: Horizontal and vertical electrostatic precipitators for power plants, cement plants, steel plants and chemical flue gas treatment

•


Application

• Automatic operation control and energy-saving optimization of boiler tail flue gas electrostatic dust removal system in thermal power units
• Flue gas purification equipment monitoring and interlock protection for cement sintering and steel smelting production lines
• Retrofit replacement and spare part stocking for old ABB Epic II dust removal control cabinets that are out of service
• Centralized signal acquisition and process logic control for industrial waste gas environmental protection treatment equipment
