Product Overview

• Part No: IS210MACCH2AEF
• Base Model: IS210MACCH2A
• Brand: GE General Electric
• Series: Mark VI / Mark VIe Speedtronic Turbine Control System
• Type: MAC Multi-function Mixed I/O Module
• Function
• Collect analog and digital signals from turbine field transmitters, vibration probes and limit switches
• Complete signal filtering, galvanic isolation and data preprocessing
• Transmit real-time field data to main processor IS210MACC1ACC via rack backplane

• Output control signals to solenoid valves, contactors and safety interlock equipment

•


Core Features

• Integrated multi-channel AI/AO/DI/DO mixed signal processing for all turbine peripheral signals
• Galvanic isolation design blocks field surge and electromagnetic interference
• Front panel LED indicators for power, running status and individual channel faults
• Conformal coated PCB for dustproof, moistureproof and anti-corrosion performance
• Standard rack plug-in card, hot-swappable under redundant power supply

• SIL 3 safety compliance for critical turbine protection loops

•


Technical Specifications

• Power Supply: 24VDC via rack backplane
• Operating Temperature: -40℃ ~ +85℃
• Protection Class: IP20, cabinet-only installation
• HS Code: 85389091

• Supply: Brand new original & fully tested refurbished modules available

•


Compatibility

• Matches GE Mark VI and Mark VIe turbine control rack
• Compatible with IS210MACC1ACC main CPU module

• Direct plug-and-play replacement for identical part number during cabinet maintenance

•


Application

• Signal acquisition and interlock control for gas turbine, steam turbine and combined cycle power units
• Fault replacement and spare part inventory reserve for power plant Mark VIe control cabinets
• Auxiliary equipment monitoring for oil & gas power generation stations
