Emerson 5X00481G04 OCR1100 controller for Ovation DCS, high-performance main processor supporting redundant bumpless failover, executes continuous control, sequence logic and interlock algorithms, compatible with local and remote I/O, critical spare for power plant and process automation systems.

Product Overview

• Part No: 5X00481G04
• Brand: EMERSON / Westinghouse Ovation

• Category: OCR1100 Process Controller Module 5X00481G04 is the OCR1100 high-performance process controller within Emerson Ovation distributed control system, serving as the core processing unit for executing PID regulation, sequential control, safety interlock and advanced control strategies. It supports 1:1 redundant configuration to realize seamless bumpless switchover upon primary controller failure, maximizing system operational availability. The controller supports local Ovation I/O branches, Q-Line I/O and remote I/O nodes, offering flexible expansion architecture for medium and large-scale control applications. Multiple Ethernet communication ports enable connection to operator stations, historians and third-party systems. Comprehensive onboard diagnostics monitor hardware status, communication links and memory performance continuously. Front panel LED indicators display running state, network activity and fault alarms for convenient on-site inspection. It serves as essential maintenance spare for thermal power, combined-cycle and petrochemical process control platforms and provides backward compatibility for legacy OCR400 controller migration projects.

•


Core Features

• High-performance OCR1100 main processor for Ovation DCS platform
• Supports 1:1 redundant deployment with bumpless automatic failover
• Executes closed-loop regulation logic, sequential control and equipment interlock algorithms
• Flexible I/O support: local Ovation I/O, Q-Line I/O and remote I/O nodes
• Multiple Ethernet communication interfaces for system networking
• Fanless low-power design for long-term stable operation
• Built-in comprehensive hardware and communication diagnostic functions
• Achilles Level 1 cybersecurity certification for critical industrial infrastructure
• Plug-in rack mounting structure, easy replacement during maintenance

• Compliant with strict industrial EMC standards for 24/7 continuous operation

•


Technical Specifications

• Model: OCR1100, part number 5X00481G04
• Power Supply: 24 VDC nominal
• Typical Power Consumption: 40 W maximum
• Supported Local I/O: Up to 16 I/O branches, maximum 128 I/O modules
• Communication Ports: Multiple RJ45 Ethernet interfaces
• Operating Temperature: 0°C ~ +60°C
• Storage Temperature: -40°C ~ +85°C
• Humidity: 5%–95% non-condensing
• Environmental Standard: Compliant with industrial control room specifications
• Mounting: Ovation standard controller rack installation

• Protection Class: IP20 when installed inside control cabinet

•


Compatibility & Application

• Fully compatible with Ovation DCS software V3.5 and above, backward compatible for OCR400 upgrade
• Supports Ovation standard I/O modules, Q-Line I/O and remote node interface modules
• Widely deployed in thermal power plants, combined-cycle power stations and petrochemical facilities
• Applied for unit coordinated control, boiler and turbine regulation, auxiliary system sequential control and safety interlock protection
