Emerson 5X00226G04 OCR1100 process controller for Ovation DCS, fanless industrial processor supporting redundant bumpless failover, executes PID regulation, sequence control and interlock logic, compatible with local and remote I/O, critical spare for power generation automation systems.

Product Overview

• Part No: 5X00226G04
• Brand: EMERSON / Westinghouse Ovation

• Category: OCR1100 Process Controller 5X00226G04 is the OCR1100 series main process controller within Emerson Ovation distributed control system. It acts as core computing unit responsible for running continuous PID control, boolean logic, sequential control, safety interlock and advanced control algorithms. This controller supports 1:1 redundant hot standby configuration to achieve bumpless automatic switchover upon primary unit failure and enhance system availability. It supports Ovation local I/O branches, Q-Line I/O and remote I/O nodes to deliver flexible I/O expansion schemes for medium and large-scale control applications. Multiple Ethernet communication ports provide connections to operator workstations, historians and third-party peripheral systems. The unit adopts fanless low-power architecture to extend service life and reduce maintenance frequency. Built-in comprehensive self-diagnosis continuously monitors hardware health, memory status and communication links. Front panel LED indicators display operation status, network activity and fault alarms for convenient field inspection. It serves as essential maintenance spare for thermal power plants, combined-cycle facilities and petrochemical process control platforms, supporting migration projects replacing legacy OCR400 controllers.

•


Core Features

• High-performance OCR1100 fanless process controller for Ovation DCS platform
• Supports 1:1 redundant deployment with seamless bumpless automatic failover
• Executes closed-loop regulation, sequential control and equipment interlock algorithms
• Flexible I/O compatibility: local Ovation I/O, Q-Line I/O and remote I/O nodes
• Multiple RJ45 Ethernet interfaces for system networking and data exchange
• Fanless low-power hardware design for long-term stable 24/7 operation
• Comprehensive onboard diagnostics covering hardware, memory and communication faults
• Achilles Level 1 cybersecurity certification for critical industrial infrastructure
• Standard rack plug-in structure for easy replacement during maintenance

• Compliant with strict industrial EMC standards for harsh control room environments

•


Technical Specifications

• Model: OCR1100, Part Number 5X00226G04
• Power Supply: 24 VDC nominal
• Maximum Power Consumption: 40 W
• Supported Local I/O: Up to 16 I/O branches, maximum 128 I/O modules
• Communication Interfaces: Multi-channel 10/100 Mbps Ethernet
• Operating Temperature: 0°C ~ +60°C
• Storage Temperature: -40°C ~ +85°C
• Humidity: 5%–95% non-condensing
• Mounting: Ovation standard controller rack installation

• Protection Class: IP20 when installed inside control cabinet

•


Compatibility & Application

• Fully compatible with Ovation DCS software V3.5 and above, backward compatible for OCR400 upgrade projects
• Supports Ovation standard I/O modules, Q-Line I/O and remote node interface modules
• Widely deployed in thermal power plants, combined-cycle power stations and petrochemical facilities
• Applied for unit coordinated control, boiler and turbine regulation, auxiliary system sequential control and safety interlock protection
