Elmo G‑TUB30480FEHSNA2 Gold‑Tuba servo drive, 3‑phase 400‑480VAC, 30A continuous output, EtherCAT STO safety for high‑power motion control applications.

Product Overview

• Part No: G‑TUB30480FEHSNA2
• Brand: Elmo Motion Control
• Category: Gold Tuba Series Servo Drive

• G‑TUB30480FEHSNA2 belongs to Elmo Gold‑Tuba high‑voltage servo drive series. It delivers high‑density power output for high‑power synchronous and asynchronous motors. Equipped with EtherCAT real‑time bus and STO safe torque‑off function, it implements position, velocity and torque closed‑loop control. Widely applied in robotics, CNC machine tools, packaging equipment and industrial automation production lines

•


Core Features

• • 30A continuous output current, high peak overload capability
• • High efficiency up to 98%, compact high‑power‑density design
• • Integrated STO Safe Torque‑Off, SIL3/PLe safety function
• • Supports EtherCAT CoE, CANopen and RS232 commissioning port
• • Multi‑feedback support: incremental encoder, absolute encoder, Hall sensor
• • Multiple built‑in digital & analog I/O for limit, homing and interlock

• • Short‑circuit, over‑voltage, over‑current and over‑temperature protection

•


Technical Specifications

• • Input: 3‑phase 400‑480VAC ±10%
• • Continuous Output Current: 30A
• • Peak Output Current: 60A
• • Control Modes: Position, Velocity, Torque
• • Communication: EtherCAT, CANopen, RS232
• • Safety: STO (SIL3 / PLe)
• • Mounting: Panel / DIN‑rail installation
• • Protection Class: IP20
• • Operating Temperature: 0℃ ~ +40℃ (derating above 40℃)

• • Software: Configurable via Elmo EASII tool

•


Compatibility

• Works with high‑voltage synchronous and asynchronous servo motors
• Compatible with EtherCAT‑based motion controller systems
• Supports multiple encoder feedback signals for closed‑loop motion
