Original CCC 10‑slot CompactPCI chassis for Vanguard Series5 compressor control system.

Product Overview

CPCI‑10‑D2 is 10‑slot CompactPCI chassis for CCC Vanguard Series5 turbomachinery control system. It acts as mechanical carrier and backplane bus backbone for processor boards, I/O modules and communication cards. Adopts dual‑star redundant backplane architecture, provides high‑speed deterministic internal bus communication for anti‑surge, load‑sharing and compressor protection logic. Equipped with forced‑air cooling and redundant power support, widely used as maintenance spare part for oil‑gas and petrochemical compressor control cabinets

Key Features

• 10‑slot CompactPCI slot layout, compatible with Vanguard Series5 series plug‑in modules
• Dual‑star redundant backplane bus for high‑availability system operation
• Supports hot‑swap function for matching CCC modules
• Forced‑air cooling design, front‑panel FAN‑FAIL status LED alarm
• Supports redundant power input, power monitoring and fault detection

• Rugged metal housing, anti‑vibration for harsh plant cabinet environment

•


Technical Specifications

• Brand: CCC (Compressor Controls Corporation)
• Model: CPCI‑10‑D2
• Type: 10‑Slot CPCI Control Chassis
• Standard: PICMG 2.0 / 2.1 CompactPCI specification
• Backplane: Dual‑star redundant bus architecture
• Cooling: Forced air fan cooling
• Power: Supports redundant power module installation
• Operating Temp: 5℃ ~ +55℃
• Storage Temp: ‑40℃ ~ +85℃
• Humidity: 5‑95% non‑condensing

• Installation: 19‑inch standard rack‑mount

•


Compatibility

Matches CCC Vanguard Series5 control modules. Backplane inspection and whole‑system configuration download are required after replacement.
