Original GE IS200TTURH1CCC S1DF00Z terminal board for Mark VI turbine system, turbine signal interface spare part.

Product Overview

IS200TTURH1CCC S1DF00Z is TTURH turbine terminal board for GE Mark VI Speedtronic turbine control system, S1DF00Z is revision code. It serves as interface between turbine field sensors, actuators and control modules, completes signal conditioning, isolation and transmission. It supports simplex and TMR triple‑redundant architecture. Conformal‑coated PCB, vibration‑resistant and anti‑interference, widely used in power‑plant turbine control cabinets.

Key Features

• Dedicated turbine terminal board for Mark VI control system
• Realizes turbine field signal conditioning, isolation and transmission
• Compatible with simplex and TMR triple‑redundant system architecture
• Conformal‑coated PCB, good anti‑vibration and EMC performance

• Standard Mark VI rack plug‑in structure

•


Technical Specifications

• Brand: GE
• Model: IS200TTURH1CCC, S1DF00Z
• Module Type: Turbine Terminal Board (TTURH)
• System Platform: Mark VI Speedtronic Turbine Control System
• Function: Turbine signal conditioning, field‑device interface
• Operating Temp: ‑40℃ ~ +85℃
• Storage Temp: ‑40℃ ~ +85℃
• Humidity: 5‑95% non‑condensing

• Installation: Plug‑in inside Mark VI control rack

•


Compatibility

Compatible with GE Mark VI Speedtronic turbine control system. After replacement, check wiring and verify turbine signal loop.
