Reuter-Stokes RS-FS-9001 is a UV flame scanner probe, adopting Silicon Carbide UV sensor, designed for gas turbine, boiler and burner flame monitoring, widely used in power plant combustion safety control system.

Product Overview

The Reuter-Stokes RS-FS-9001 flame detector (flame scanner probe) is a high-performance ultraviolet flame sensor for combustion safety monitoring. It uses silicon carbide UV photodiode to capture ultraviolet radiation generated by flame, identify flame presence or flame loss quickly. With rugged stainless steel housing and optional water cooling structure, it can withstand high temperature and vibration in combustion chamber surroundings. It transmits flame status signal to combustion control system, to trigger alarm or fuel cut-off protection upon flame out, ensuring safe operation of gas turbines, boilers and industrial burners.

Key Features

• Silicon Carbide UV sensor for ultraviolet flame detection
• Fast response for flame on / flame loss judgment
• Stainless steel rugged housing for harsh high-temperature environment
• Water-cooled version available for high ambient temperature application
• Excellent anti-interference capability, resist sunlight and electric arc interference
• Built-in optical window self-check and contamination diagnosis function
• Hazardous area certification for explosive gas zone installation
• Simple mechanical threaded mounting, convenient for burner assembly

• Long service life, stable performance for continuous combustion monitoring

•


Technical Specifications

• Brand: Reuter-Stokes (Baker Hughes / GE)
• Model: RS-FS-9001
• Sensing Principle: UV ultraviolet detection, SiC photodiode
• Max operating temperature: 150℃ (water cooling optional)
• Detection fuel: Natural gas, fuel oil and multi-combustion media
• Housing material: Stainless steel
• Protection: IP65
• Certification: ATEX, IECEx, CE

• Mounting: Threaded installation on burner casing

•


Compatibility & Application

Compatible with GE combustion controller, burner management system (BMS), gas turbine control system. Mainly applied in gas turbine, power plant boiler, industrial burner, reformer furnace, oil & gas processing combustion safety monitoring, flame loss protection and ignition confirmation.
