TeIKOOR PSMU-350-3 CPCIAC-6U-500 900-7002-10 is a 6U CompactPCI AC/DC power supply with 500W continuous output, universal AC input, active PFC and hot-swap function, built-in I2C monitoring for industrial and rugged CPCI systems.

Product Overview

TeIKOOR PSMU-350-3 (CPCIAC-6U-500, part number 900-7002-10) is a high reliability 6U CompactPCI AC power supply module. It adopts active power factor correction design, providing standard CPCI multi-channel DC outputs. The module supports hot-swap and redundant parallel operation, with I2C intelligent bus monitoring for real-time status readout, voltage/current/fault alarm. Widely used in industrial control, test measurement, telecom and rugged embedded CompactPCI chassis systems.

Key Features

• 500W continuous output, 6U CompactPCI form factor
• Universal AC input: 85~264VAC, wide global voltage range
• Active PFC power factor correction, high conversion efficiency
• Standard CPCI multi-output: +3.3V, +5V, +12V, -12V
• Hot-swap capable, support redundant power configuration
• I2C bus interface for remote monitoring and fault diagnosis
• Low ripple and noise, tight line & load regulation
• Built-in over-voltage, over-current, over-temperature protection

• Rugged construction, designed for harsh industrial embedded environments

•


Technical Specifications

• Model: PSMU-350-3, CPCIAC-6U-500
• Part No: 900-7002-10
• Form Factor: 6U CompactPCI
• Rated Output Power: 500W
• AC Input: 85VAC ~ 264VAC
• DC Output: +3.3V, +5V, +12V, -12V
• Communication: I2C intelligent monitoring bus
• Protection: OVP, OCP, OTP, short circuit protection
• Cooling: Forced air cooling

• Certification: CE, UL, FCC

•


Compatibility & Application

Compatible with standard 6U CompactPCI backplanes and CPCI chassis. Applied in industrial embedded control, data acquisition, test systems, telecommunications equipment and military-grade rugged computing platforms.
