GE DS200TCQCG1AJD is an overflow control circuit board designed for GE Speedtronic Mark V gas turbine control system, responsible for signal overflow processing and analog signal conditioning, critical spare part for power generation turbine control rack.

Product Overview

GE DS200TCQCG1AJD is a rack-mounted printed circuit board belonging to GE Speedtronic Mark V turbine control system. This overflow board handles R-S-T signal overflow monitoring and signal conditioning, collects and processes analog measurement signals from field sensors, provides signal scaling and limit judgment. It works cooperatively with QP processor module to realize real-time monitoring and protection logic for gas turbine, widely used in power plant gas turbine control cabinets.

Key Features

• Specialized overflow signal processing board for GE Mark V Speedtronic turbine control
• Process R, S, T three-phase signal overflow detection and conditioning
• Analog signal acquisition, scaling and threshold judgment function
• Designed for rack installation inside turbine control cabinet
• With on-board circuit for signal filtering and noise suppression
• Conformal coated PCB, resistant to moisture, dust and corrosive gas
• Stable signal transmission for turbine protection and monitoring logic

• Industrial grade long life design for continuous power generation operation

•


Technical Specifications

• Model: DS200TCQCG1AJD
• Brand: GE General Electric
• Product Type: Overflow Control Board
• Series: Speedtronic Mark V Gas Turbine Control System
• Installation: Rack mount inside control cabinet
• Function: R-S-T signal overflow monitoring & analog signal conditioning
• PCB Type: Conformal coated printed circuit board
• Application Environment: Power generation turbine control cabinet

• Operating Temperature: 0℃ ~ 60℃

•


Compatibility & Application

Compatible with GE Speedtronic Mark V gas turbine control rack, matched with QP processor boards and related I/O modules. Mainly applied in power station gas turbine unit control, turbine protection monitoring and power generation industrial control system maintenance and spare replacement.
