EMERSON KJ3203X1-BA2 (13P0085X022, VE4001S2T2B4) is a 32-channel 24VDC dry contact discrete input module for Emerson DeltaV DCS system, used to collect passive switch signals and digital status from field devices, with group isolation and built-in fault diagnosis.

Product Overview

EMERSON KJ3203X1-BA2 is a standard S-series I/O board of Emerson DeltaV distributed control system, with part number 13P0085X022 and model code VE4001S2T2B4. It is a 32-channel digital input card designed for acquiring 24VDC dry/wet contact switch signals from field instruments, valves, limit switches and relay contacts. The module transmits collected discrete status data to DeltaV controller through the local I/O bus, supports configurable input filter for contact bounce suppression. It adopts group photoelectric isolation design, effectively reduces field interference, widely used in petrochemical, power, pharmaceutical process control systems.

Key Features

• 32 channels digital input, supports 24VDC dry contact and wet contact signal
• Group photoelectric isolation, 1500V isolation voltage, strong anti-interference performance
• Configurable software filter to eliminate contact jitter and signal noise
• Compatible with passive dry contact and active NPN/PNP field sensors
• Built-in comprehensive self-diagnosis, open circuit and fault status indication
• Hot-swappable design, can be replaced online without system shutdown
• Installed in DeltaV S-series I/O rack, matched with dedicated terminal block
• Compact structure, conforms to industrial cabinet continuous operation requirements

• Supports ATEX/IECEx certification for hazardous area installation

•


Technical Specifications

• Model: KJ3203X1-BA2
• Part Code: 13P0085X022
• Functional Model: VE4001S2T2B4
• System Series: Emerson DeltaV DCS S-Series I/O
• Channel: 32 discrete input channels
• Rated Field Voltage: 24VDC (19.2~28.8VDC)
• Input Threshold: High ≥11VDC, Low ≤3VDC
• Isolation: Group isolation, 1500VDC
• Typical Response Time: 5ms, filter time configurable
• Power Consumption: Typical 5W
• Operating Temperature: -40℃ ~ +70℃

• Relative Humidity: 5~95% non-condensing

•


Compatibility & Application

Compatible with Emerson DeltaV S-series I/O rack, DeltaV controller and matched terminal blocks. Applied in oil & gas, chemical, power, pulp and paper industry for valve limit switch, relay status, field on/off digital signal acquisition and process state monitoring.
