Brand:Allen-Bradley

Model:1769-L16ER-BB1B

Controller Type:CompactLogix

Memory Capacity:384 KB

Expansion Capabilities:Up to 6 modules

Digital Inputs:16 DI (sink)

Digital Outputs:16 DO (source)

Backplane:POINT bus

Ethernet Ports:2 DLRs

Network Communications Class:1, 3

TCP Connections:4

Storage Capacity:1 GB

    The Allen-Bradley 1769-L16ER-BB1B CompactLogix 5370 Ethernet Controller is a high-performance solution tailored for modern industrial automation needs. This controller boasts a robust architecture designed for seamless integration with existing systems, ensuring efficient data exchange and control over industrial processes.

    With its compact design and compatibility with Allen-Bradley's 1769 backplane, the 1769-L16ER-BB1B provides a flexible platform for expanding functionality through additional I/O modules. It is equipped with advanced communication capabilities, supporting multiple protocols including Modbus TCP/IP, facilitating interoperability across various industrial networks.

    Featuring a large memory capacity of 384 KB, the controller ensures ample space for storing programs, data, and user configurations. Its ability to support up to six expansion modules allows for scalability, accommodating growth in system requirements without compromising performance.

    Equipped with two Ethernet ports (DLRs), the controller enables fast and reliable data transfer, crucial for real-time monitoring and control applications in industries requiring high-speed data processing. Additionally, it supports class 1, 3 network communications, ensuring compatibility with a wide range of industrial standards.

    The inclusion of four TCP connections further enhances its versatility, allowing for concurrent connections to different devices or systems. This feature is particularly beneficial in complex industrial setups where multiple remote devices need to be controlled or monitored simultaneously. With a storage capacity of 1 GB, the controller can handle extensive data processing and storage demands, making it suitable for demanding applications.
