Net Weight (kg):0.745

Packaging Dimensions:13.20 x 15.20 x 13.10 cm

Manufacturer(s):SIEMENS

Model Type:SIMATIC S7-300

CPU Model Number:6ES7314-6BG03-0AB0

Net Weight (lbs):Approximately 1.64 lbs

Power Supply:Integrated 24 V DC

Work Memory:96 KB

Input/Output:24 DI/16 DO, 4 AI, 2 AO

Additional Features:1 Pt100, 4 high-speed counters (60 kHz), front connector (2x 40-pole) and Micro Memory Card required

    The SIEMENS SIMATIC S7-300 Compact CPU 314C-2 PTP with MPI boasts an efficient and compact design, making it perfect for space-constrained industrial applications. This CPU is equipped with an integrated MPI interface for seamless communication between devices, enhancing productivity and reducing wiring complexity.

    With a high-speed processor capable of reaching up to 1 MHz, this CPU ensures rapid processing of control tasks, ensuring smooth operation in demanding industrial settings. The 96 KB of working memory allows for the execution of complex programs without the need for additional memory cards.

    Featuring 24 Digital Inputs (DI) and 16 Digital Outputs (DO), the CPU supports a wide range of input and output configurations, facilitating versatile control over machinery and processes. The addition of 4 Analog Inputs (AI) and 2 Analog Outputs (AO) enables precise measurement and control in applications requiring analog signals.

    An integrated 24 V DC power supply ensures reliable power delivery directly from the CPU, eliminating the need for external power supplies and simplifying installation. The CPU is designed to operate within a temperature range of -25°C to +60°C, ensuring robust performance under various environmental conditions.

    Certified with CE, UL, and CSA, the CPU meets international safety and quality standards, providing peace of mind for users. Its modular and scalable design allows for easy integration into existing systems or expansion as needs evolve, making it a flexible choice for a variety of industrial automation projects.
