Model Type:High Capacity IP Module

Model Number:1756EN2T

Manufacturer:Allen Bradley

Communication Module Type:ControlLogix

Power Supply:3 MA at 24 VDC

Mounting:Chassis

Communication Speed:10/100 MBPS

Communication Protocol:Ethernet/IP Bridge

Enclosure:Open Type

Connection Cables:802.3 compliant shielded or unshielded twisted pair

Temperature Rating:0 – 60 DEG C

Power Dissipation:5.1 W

Isolation:30 V continuous

Environmental Conditions:5 – 95% non-condensing relative humidity

Vibration Resistance:2 G

Shock Resistance:30 G

Interface:Ethernet

USB Port:Not applicable

    The Allen-Bradley 1756-EN2T Ethernet/IP Bridge Module is engineered to provide reliable and efficient data exchange in complex industrial settings.

    With its robust design and high-speed Ethernet/IP interface, this module ensures seamless integration with ControlLogix systems, enhancing operational capabilities.

    Featuring a compact yet powerful architecture, it supports a wide range of communication protocols, making it compatible with diverse industrial equipment.

    Its open-type enclosure ensures compatibility with various mounting options, allowing for flexible installation in different industrial environments.

    Equipped with advanced isolation technology, it ensures secure data transmission even under challenging environmental conditions, guaranteeing system uptime and reliability.

    This module comes with a USB port for easy configuration and firmware updates, streamlining maintenance and system management processes.
