Resolution:16-bit incremental output

Operating Voltage:24V DC

Frequency Response:Up to 10 kHz

Rotary Range:0 to 360°

IP Rating:IP67

Temperature Range:-25°C to +85°C

Material:Aluminum alloy

Connectivity:Industry-standard connector

Shaft Configuration:ISO 9409-2 shaft

Mounting Options:Bore and flange mounting

    The SIEMENS HC202500/0XX0XM5 Industrial Rotary Encoder is a state-of-the-art solution for industries demanding precise and reliable angular measurement capabilities. Crafted with an aluminum alloy housing for durability and strength, this encoder is engineered to withstand challenging industrial conditions.

    Featuring an advanced design with a stainless steel shaft, it ensures smooth operation and longevity, even in harsh environments. The 5000 counts per revolution provides exceptional angular resolution, while its accuracy of +/- 0.25 degrees guarantees precision in critical applications.

    Operating within a temperature range of -25°C to +85°C, this encoder is versatile enough to handle various industrial settings. It supports a wide power supply voltage of 5V DC, making it compatible with diverse systems.

    With its 4-wire differential signal output, the encoder offers high signal integrity and noise immunity, ensuring accurate data transmission under varying conditions. Its IP67 protection class ensures it can resist dust and water ingress, maintaining functionality in wet or dusty environments.

    Capable of handling operating frequencies up to 1000 RPM and rotation speeds up to 2500 RPM, the SIEMENS HC202500/0XX0XM5 is suitable for a broad range of machinery and equipment, from conveyor systems to robotics, where precise angular measurements are crucial for performance and safety.
