Memory Capacity:1MB

Maximum Expansion Modules:Up to 8

Backplane Compatibility:POINT Bus

Network Ports:2 Ethernet

Input/Output Channels:16 DI (sink), 16 DO (source)

Motion Control Support:2 servo drive connections

Communication Classes:Class 1, 3 networks

TCP Connections:8

Support for CIP Motion:Yes

    Engineered with advanced technology, the AB 1769-L30ER CompactLogix controller stands out in its class for its robust performance and reliability in industrial automation environments.

    Featuring a generous 1MB of user memory, this controller ensures ample space for complex programs and data management, facilitating efficient operations across various sectors.

    With Ethernet connectivity at its core, the controller enables seamless integration and data transfer within a network, enhancing communication efficiency between different components.

    Designed to support up to eight expansion modules, the AB 1769-L30ER offers flexibility in adding functionality without compromising system performance, making it suitable for diverse application needs.

    Equipped with compatibility for Class 1 and Class 3 networks, along with support for up to eight TCP connections and two servo drive connections, this controller ensures a versatile and adaptable solution for modern industrial automation challenges.

    Operating within a temperature range from -40°C to 85°C, the controller is engineered to withstand harsh industrial conditions, ensuring reliable operation under varying environmental conditions.
