Operating Voltage:DC 24V

Measurement Range:-10V to +10V

Sampling Rate:up to 1 kHz

Accuracy:±0.01% of reading + 1 LSB

Communication Protocol:EtherCAT

Dimensions:85mm x 105mm x 35mm

Weight:0.2 kg

    The ABB DSQC633D 3HAC048550-001 measurement board is engineered to meet the demanding requirements of modern industrial automation environments. Its advanced technology ensures accurate and reliable data acquisition, making it an indispensable tool for engineers seeking to optimize production processes.

    Featuring a robust design and compact size, this measurement board seamlessly integrates into various industrial setups, enhancing system efficiency and performance. With its high-speed data processing capabilities, it supports real-time monitoring and control, enabling quick response to operational changes.

    Equipped with DeviceNet and Profinet communication protocols, the DSQC633D offers seamless connectivity with a wide range of ABB and third-party devices. This compatibility ensures a cohesive and efficient integration within complex industrial networks, facilitating easier maintenance and scalability.

    Operating within a temperature range from -20°C to +70°C, the board is built to withstand harsh industrial conditions, ensuring reliability in diverse environments. Its low current consumption and efficient power management contribute to energy savings, aligning with sustainable manufacturing practices.

    Designed with user-friendliness in mind, the DSQC633D comes with comprehensive documentation and support, enabling rapid deployment and minimizing setup time. Its modular architecture allows for easy expansion and customization, meeting the evolving needs of industrial automation projects.
