Power Rating:400 kW

Voltage Rating:1200 V

Current Rating:1200 A

Operating Temperature Range:-40°C to +150°C

Insulation Resistance:≥ 10 MΩ @ 500 VDC

Cooling Method:Water Cooled

Input Signal Type:Digital Control Signals

Switching Frequency:Up to 10 kHz

Package Size:172 x 148 x 58 mm

Net Weight:1.5 kg

    Integrating advanced semiconductor technology, the ABB FF400R12KE3 IGBT Module ensures seamless operation across a wide range of industrial processes. Its robust design withstands extreme environmental conditions, making it ideal for use in heavy machinery and power-intensive systems.

    The module boasts a high switching frequency of 12 kHz, enabling fast and precise control of power flows, which is critical for optimizing efficiency and reducing energy consumption in manufacturing processes.

    With an operating temperature range from -40°C to +175°C, this IGBT Module is suitable for applications in harsh environments, ensuring continuous performance even under challenging conditions.

    Featuring a water-cooling system, the FF400R12KE3 IGBT Module efficiently manages heat dissipation, enhancing its reliability and extending its lifespan in high-power applications.

    Offering an insulation class of F, the module ensures a high level of electrical safety and reliability, protecting against overvoltage and ensuring consistent performance over time.
