Operating Protocol:Modbus

Communication Speed:9600 bit/s

Max Drives Capacity:31 drives & 1 panel

Unique ID Requirement:Each station requires a unique ID number

Control Panel Indicators:["Loc Keypad","Forward Start","REM External Control","RESET Fault Reset","REF Reference Setting Function"]

Operational Commands:["Change Mode","ID-NUMBER Entry","Accept New Value","Drive Name + Version","Downloaded FCB Application"]

    The ABB CDP312 Control Panel Keypad is a pioneering solution for industrial automation, engineered to provide unparalleled control and precision in manufacturing environments. Designed with a user-centric approach, it ensures seamless integration with ABB drives and other compatible systems, enhancing operational efficiency.

    Featuring Modbus protocol compatibility, this keypad enables robust communication across up to 31 drives and one control panel, ensuring a scalable and flexible automation setup. Each station is uniquely identified to streamline management and maintenance tasks.

    Equipped with LED indicators, the CDP312 provides real-time feedback on system status, enabling operators to monitor and adjust parameters efficiently. The keypad supports essential commands like Location (LOC), External Control (REM), Reset (RESET), and Reference Setting (REF), facilitating quick and accurate control adjustments.

    With support for individual drive IDs, the ABB CDP312 Control Panel Keypad allows for the precise selection and management of drives within the system, optimizing performance and minimizing downtime. Its compact yet robust design makes it suitable for a wide range of industrial settings, from automotive manufacturing lines to energy-intensive processes.

    For industries seeking to enhance their productivity and efficiency, the ABB CDP312 Control Panel Keypad offers a comprehensive solution that integrates seamlessly with existing infrastructure, providing a future-proofed approach to automation.
