Power Rating:400 kW

Switching Frequency:up to 12 kHz

Current Rating:1200 A

Cooling Method:Water-cooled

Insulation Class:F

Operating Temperature Range:-55°C to +125°C

Dimensions (WxHxD):120 mm x 100 mm x 125 mm

Weight:2.8 kg

    The ABB FF400R12KE3 Dual IGBT Module is engineered to meet the stringent demands of modern industrial automation environments. With its robust design and advanced semiconductor technology, this module ensures unparalleled performance across a wide range of applications.

    Featuring a high current rating and peak current capability, it is ideal for power-intensive tasks, such as motor control and drive systems, where efficiency and reliability are paramount.

    Operated within an extensive temperature range of -40°C to +170°C, the FF400R12KE3 is designed to withstand harsh industrial conditions, ensuring consistent operation in diverse environments.

    Equipped with a thermal pad cooling system, the module efficiently manages heat dissipation, prolonging its lifespan and reducing the risk of overheating, a common issue in power electronics.

    Its panel mount design facilitates easy integration into existing systems, minimizing installation time and complexity. The compact size and lightweight construction make it a versatile choice for space-constrained applications.

    ABB’s commitment to innovation is evident in the FF400R12KE3 Dual IGBT Module, which not only delivers superior performance but also aligns with industry standards for safety and sustainability.
