Manufacturer:ABB

Model:SDCS-PIN-205B 3ADT312500R0001

Series:Advanced Power Control

Type:Interface Board

Dimension (LxWxH):150mm x 100mm x 30mm

Weight:0.25kg

Operating Voltage Range:24V DC

Power Consumption:15W

Communication Protocol:MODBUS TCP/IP

Input Current:10A

Output Current:5A

Number of Inputs/Outputs:8/8

Operating Temperature Range:-20°C to +60°C

Storage Temperature Range:-40°C to +85°C

    This ABB Power Interface Board is engineered to deliver high performance in industrial automation applications, ensuring robust operation under various environmental conditions. The board features advanced circuitry designed for efficient power management and signal processing, enhancing system responsiveness and accuracy.

    With its comprehensive input/output capabilities, it facilitates easy integration with other components in your control system, supporting diverse signal types including digital inputs (DI), digital outputs (DO), analog inputs (AI), and analog outputs (AO).

    The inclusion of Safe Torque Off feature ensures safety during system shutdown or maintenance procedures, preventing unintended torque application and protecting personnel and equipment.

    Designed for seamless compatibility with major fieldbus protocols, this board supports communication standards widely used in industry 4.0 environments, enabling real-time data exchange and enhanced system monitoring.

    Manufactured using high-quality materials, the board is built to withstand the rigors of industrial use, offering long-term reliability and minimizing downtime. It is compatible with a wide range of ABB industrial controllers, ensuring a seamless integration experience within existing automation setups.
