Model:AI830

Type:Analog Input Module

Manufacturer:ABB

Product Code:3BSE008518R1

Module Size:Compact

Power Consumption:Low

Operating Temperature Range:-25°C to +70°C

Signal Range:0 to 10 VDC or 4 to 20 mA

Accuracy:+/- 0.1% of full scale

Response Time:Less than 10 ms

Connection Type:Terminal Block

Input Channels:8

Communication Interface:DeviceNet, Modbus TCP/IP

Weight:0.24 kg

Dimensions:125 x 100 x 90 mm

Mounting Type:Panel

Certifications:CE, UL, CSA

    The ABB AI830 3BSE008518R1 Analog Input Module is a key component in industrial control systems, ensuring seamless integration with ABB's advanced PLCs and other automation solutions. With its high-resolution 12-bit analog inputs, this module delivers precise data acquisition, essential for optimizing process control and enhancing efficiency in manufacturing environments.

    Engineered for robust performance, the AI830 is capable of handling a wide range of voltage inputs from 12V to 24V DC, making it suitable for various industrial applications. Its low current consumption per channel ensures efficient power usage without compromising on signal integrity.

    Featuring a modular communication interface, the module supports flexible installation and configuration, enabling easy expansion and integration into existing systems. Its IP20 environmental rating ensures protection against dust and light splashes, safeguarding the module in challenging industrial settings.

    Operated within a temperature range from -25°C to +55°C, the AI830 is designed for reliable performance in diverse climates. For storage, it can withstand temperatures from -40°C to +85°C, ensuring long-term durability.

    Compact yet powerful, the AI830 measures 74mm x 120mm x 100mm, making it an ideal fit for space-constrained environments. Weighing approximately 0.5kg, it offers convenient handling and installation. This module is not just about functionality; it's about enhancing the overall system performance, contributing to the success of industrial automation projects.
