Manufacturing Origin:Switzerland

Model Code:5SHX0845F0001 3BHL000385P0101 5SXE05-0151

Type:IGCT Module

Certification:ISO 9001, CE

Material:High-grade copper and aluminum alloys

Dimensions (WxHxD):200mm x 100mm x 50mm

Weight:3.5kg

Operating Temperature Range:-40°C to +70°C

Current Rating:Up to 500A

Voltage Rating:Up to 1500V DC

Switching Frequency:Up to 5kHz

    The ABB 5SHX0845F0001 3BHL000385P0101 5SXE05-0151 IGCT Module boasts an innovative design that combines superior thermal management with robust mechanical stability, ensuring long-lasting performance under demanding conditions.

    Engineered for seamless integration into complex power systems, this module excels in applications requiring precise control over electrical power flow, such as renewable energy conversion, motor drives, and industrial automation.

    Crafted with high-grade copper and aluminum alloys, it offers exceptional conductivity and durability, making it suitable for high-power applications without compromising on efficiency.

    With an operating temperature range of -40°C to +70°C, this module ensures reliable operation in a wide variety of environmental conditions, from freezing cold to extreme heat.

    Featuring a current rating of up to 500A and a voltage rating of up to 1500V DC, it provides a versatile solution for power management tasks, supporting a broad spectrum of power handling needs.

    Innovative switching frequency capabilities of up to 5kHz enable rapid response times and efficient power conversion, enhancing system performance and reducing energy losses.
